Features
Automatic Cocoa Beans Weighing Packaging Machine is a kind of multi-head scale granules packaging machine, which is suitable for fixed weight packing of granule materials such as paddy, wheat, rice, corn, seeds, granule feedstuff and compound fertilizer, etc. The cocoa beans packaging machine is with good sealing performance and can meet customer's hygienic requirements.

Features of automatic cocoa beans packaging machine:

Features of automatic cocoa beans packaging machine:
- Adopts servo motor for film pulling with automatic offset correction. Two types of driving motor, i.e. cylinder and servo can be adopted for horizontal sealing.
- Off-the-shelf components ensure quick service response.
- No-tool changeover, user-friendly operation process.
- All the electrical components adopt local and foreign well-known brands with reliable performance
- Two types of vertical sealing mechanism, i.e. center sealing type and platen press type (the user can choose according to specific material and the film roll).
- Robust, stainless steel frame.
The multi-head scale beans packaging machine is a weighing device, and the principle of the multi-head scale mainly utilizes the principle of combined weighing. Through the combination of the number of heads, the purpose of weighing is achieved, that is to say, the more the number of heads, the more the combination scheme is, the faster the speed is, and the higher the precision is. The electronic beans packing machine has 10 heads scales, 14 scales, 16 scales, 24 scales and more, each of which is a separate scale. It can be weighed independently.


Technical Data
Electronic scale | Vertical packaging machine | ||
Model | LG14A-1.6 | model | LGLK 420 |
Voltage | AC110/220V | Film width | MAX 420mm |
Power frequency | 50/60HZ | Bag width | 80-200mm |
Rated current | 10A | Bag length | 50-300 twice pull film 400mm |
Power | 2.0KW | Packing speed | 15-80 bag/min |
Weighing number | 14 | Measuring range | 150-1500ml |
Weighing rang | 3-6500g | membrane thickness | 0.04-0.10mm |
Single weighing range | 10-1200g | Power Specifications | 2.5kw/220v 50-60hz |
Weighing capacity | 1600ml | Machine size | 1400×970×1700 |
Maximum weighing speed | 130p/min | Machine quality | 450kg |
Product preset number | 100 | Air consumption | 0.4 cubic / minute 0.6mpa |
Long form factor | 1020mm | Packaging material |
Bopp/cpp. Bopp/vmcpp bopp/pe. Pet/vmpet/pe pet/al/pe ny/pe pet/pet |
Wide size | 960mm | ||
High profile | 1400mm | ||
Machine weight | 420kg | ||
monitor | 10.4inch | ||
Weighing accuracy | plus or minus 0.3-3 grams |
