Features
Granules Pouch Packing Machine applicable to a variety of prefabricated bags fully automatic bag-opening-filling-sealing-printing date and finished product delivery, etc, compact, low investment, fast return, suitable for small and medium-sized packaging manufacturers.
Features of the granules beans filling machine:
1. Convenient operation: It adopts PLC control and is equipped with touch screen man-machine interface control system, which is easy to operate.
2. Frequency control: This machine uses the frequency conversion speed control device, the speed can be adjusted freely within the specified range.
3. Automatic detection function: If the bag is not opened or the bag is incomplete, no feeding, no heat sealing, the bag can be reused, no material is wasted, and the production cost is saved for the user.
4. Safety device: When the working pressure is abnormal or the heating pipe is faulty, an alarm will be given.
5. Horizontal bag feeding mode: The bag storage device can store more bags, which has lower requirements on the quality of the bag, and the rate of bag sharing and bagging is high.
6. Adjust the bag width by motor control. Press and hold the control button to adjust the width of each group at the same time. It is easy to operate and saves time.
7. In line with the hygiene standards of the food processing industry, the parts on the machine that come into contact with the materials or packaging bags are processed with stainless steel or other materials that meet the food hygiene requirements to ensure the hygiene and safety of the food.
Technical Data
Model | LGLD-320 | LGLD-350 |
Bag Size Macking |
L: 50-150 mm W: 40-150 mm |
L: 30-180mm W: 30-140mm |
Packing Speed | 40-60Bags/min | 30-60Bags/min |
MeasureRange | 20-100g | 5-100g |
Thickness Of The Packing Film | 0.03-0.08mm | 0.05-0.1mm |
Total Power | 3KW/220V | 2.5KW/220V |
Diameter of the Rolling Paper | =<450 | <=450 |
Dimensions(mm) | 750*980*1680 | 820*980x1680 |
Gross Weight | 300kg | 400Kg |
