Features
The A4 copy pape packing machine using material is cellophane and OPP Film, is common machine for different specification hard paper packing box, packing product, A4 copy paper etc. 3D packing. Transparent paper/film and a printed graphic or holographic laser mark folding line are bonded by adhesive, convenient for unpacking and anti-counterfeiting.
The machine work rely on a series of cams within the machine, which drive a variety of connecting rod and components to complete working. It uses multi-function digital frequency stepless speed control, PLC programming control technology, automatic feeding box, automatic counting, touch display to achieve human-computer interface. Pneumatic falling film, at the same time many boxs packing, machine is working stable.
Technical Data
Model | LG-297C |
Packing Speed | 10-15pcs/min |
Packing Specification |
297*210*(48-60)mm (If based on A4 paper, pack 500pcs) |
Voltage |
220V, 50Hz, Single Phase 380V, 50Hz, Three Phases |
Power | 4.5kw |
Air Pressure | 0.4Mpa |
Dimension | 3200*1100*1900mm |
Weight | 1200KG |
Suitable Film |
Inner Roll Diameter 76mm Roll Film Max Diameter is 800mm |
