Features
Automatic carton box heat shrink packaging machine is designed with lengthened double hot wind tunnel for higher and better shrinking effect, which is widely applied for outer shrink packing of various products, such as foodstuff, beverage, pharmacy, video disc, hardware, cosmetics, books, toys and electronic products etc.To use in place where there is restriction on space, such as supermarket, monopolization shop, office and some laboratory etc
Characteristic of autoamtic toy box shrink packaging machine:
1. The machine adopts heating and stickiness free seal knife, which ensures the machine running well and without smoke.
2. The time, transferring the products to the tunnel after sealing and cutting, is adjustable.
3. Only one controlling board makes the operation easily.
This toy box automatic shrink wrapping machine is suitable for industries: suitable for products such as furniture, sheet metal, home appliances and other products in POF / PE film packaging. After packaging, the product can prevent dust, moisture, looseness, and protect the product, which is conducive to transportation and storage.
1. "Panasonic" PLC control, with "Kinco" multi-language touch screen display, intuitive operation, simple, more stable computer control system operation, clean working environment, low noise, can adjust any parameters without stopping, display production speed, batch It also has the function of self-diagnosis of equipment failure, which can store ten sets of parameters, making it easier and faster to change the variety;
2. It adopts straight-in feed, supporting feeding belt conveyor and discharging belt conveyor, which can be used independently, and can also be connected automatically with upstream and downstream equipment to realize fully automatic packaging.
3. PID digital temperature control, sealing temperature deviation ± 1 degree, independent horizontal and side sealing knife temperature control, to achieve more uniform heating and more stable temperature control.
4. In line with European CE safety standards, the use of three-color lights + buzzer sound and light to display the machine's operating status, this toy box heat shrink packaging machine can achieve long-range observation of the dynamics of the device, when the machine is operating normally, the safety cover will immediately stop the machine, and send out alerts to prevent accidents.
Video:
4. In line with European CE safety standards, the use of three-color lights + buzzer sound and light to display the machine's operating status, this toy box heat shrink packaging machine can achieve long-range observation of the dynamics of the device, when the machine is operating normally, the safety cover will immediately stop the machine, and send out alerts to prevent accidents.
Video:
Technical Data
PE thickness | 0.04-0.1mm |
The width of heating cutting blade | 1800mm |
Height of product | ≤600mm |
Packing speed | 5-15pcs/Min |
The max speed of conveyor | 20m/min |
Gas source | 0.6-0.8Mpa,20liter/min |
Power specification | 380/220V 3PH 50/60HZ 7.5KW |
Dimension | L4255*W3438*H1780mm |
Packing size | L4380*W2330*H1950mm |
Gross Weight/Net Weight | 1750/2250kg |
